Astec 13-3680

Description: Frame- Heavy-duty lattice type Idlers- All standard idlers are CEMA B – 5” [127mm] diameter 35 degree troughing idlers on 4’ [1.2m] spacing 20 degree idlers at feed point close spacing Flat steel return idlers on 10’ [3m] spacing Undercarriage- Manual telescoping pin lock- Axle – single axle with single 11:00 – 22.5 tires on swivel wheel boxes (42” [1,067mm] belt width includes dual tires) Receiving Trough- 5’ 6” [1.7m] long with adjustable rubber flashing Belt Drive- Head end drive- 3/60/230-460 TEFC electric motor- Class I Dodge® shaft mount reducer with backstop- V-belt, motor mounts and guards- 3/8” [9.5mm] grooved, head pulley- Steel wing tail pulley- 18” [457mm] Screw take-up- Belt Speed - 350 FPM [1.7 MPS] Enginerebuilt: 0 Transmissionrebuilt: 0
