BIK TC-98
Price excl. VAT
POA
7
Favorite
Share
Save search
Report suspicious displayINFO
Product category / Group
Crane trucks
Brand / model
BIK TC-98
Extra options
New/unused
Location
Milford, Massachusetts
Country
United States
General grade
1
2
3
4
5
Mascus ID
CB96D9A7
DETAILS
Other information/spec
BOOM DETAILS
New – BIK Tree-Care Series TC-98 – 54.5 ton/m
Knuckle Boom
6 ext Knuckle Boom w/Detachable 3 ext jib + 1-grapple extn
Including (1) Grapple extension in jib,
Boom Capacity of
2,230 lbs ... 98’ Vertical
Reach
Main Boom Horizontal Capacity:
21,000 lbs ... 14’
10,900 lbs ... 25’ 8”
6,800 lbs ... 38’ 8”
4,830 lbs ... 53’ 6”
Jib Horizontal Capacity:
2,100 lbs ... 63’
1,850 lbs ... 75’ 4”
1,700 lbs ... 82’
Grapple main extension to 86’
“Power-Link”
connecting rods at First Boom and Knuckle, Double pilot operated on slewing and pilot check valves on all cylinders
Planetary Gear Rotation Motor
& Continuous Boom Rotation
– for maximized slewing torque and reliability
15 Degree negative angle
on main knuckle,
20 degree negative angle
on jib
– Hyd Extra Wide Main outriggers
at base – 25’ 7” total span
Auxiliary Stabilizers
– Extra wide type – 21’ span
, hyd out & down type at rear – Front Bumper Hyd Stabilizer
– 100% stability 360 degrees
Two Hydraulic Oil Coolers
, high pressure return filter and 100 gal custom hydraulic oil tank with Enviro-Friendly
AW-46 weight Hyd Oil
Tandem pump / split valve
pressure system for optimum speed for simultaneous
multi function use
DANFOSS
Proportional Control Valve at Top Seat
SCANRECO
Proportional Radio Remote Control
w/2 batteries, charger
Engineer Stability load tested and certified
Warranty: 1-Yr. part & labour on entire boom, 3-Yr. on Structural Components
DECK DETAILS
New
– 10’ 8” x 102”
Steel Checker plate Flat Deck
Checker plate steel deck surface
48” head board, sliding winch straps
Rub rail & pockets on side
Dual sided access ladders
Primed & painted gloss black
TRUCK DETAILS
New – Freightliner 108SD
4-axle
Day Cab Truck:
69,000 lb GVWR
CUMMINS
Diesel
380 HP
– Allison Automatic Trans
.
20,000 LB fronts with 425 / 65R22.5 tires on Aluminum Rims
40,000 LB Rears on Tuftrac suspension with 11R22.5 tires on Aluminum outer rims
9,000 lb self steer tag axle behind t/a with 17.5” tires/alum rims
166” wheel base
Double Frame with integral front bumper frame extension (for front stabilizer)
Chrome single polished Exhaust pipe side of cab
Chromed Grille & Bumper, single 80 gallon alum fuel tank,
A/C, Tilt/Telescopic steering, AM/FM radio with Bluetooth, power windows & locks, air high back driver’s seat, cruise,
heated mirrors, inter-axle and diff lock-ups, Cab White,
Air ride cab, full differential locks, exterior sun visor, etc…
Also Included Are
:
(5) pcs – 2” PVC stab pads w/holders
(2) pc Alum storage boxes installed
Custom re-enforced manual extn for grapple,
New Mecanil SG-280 Grapple saw with spare parts
2 to 3 day on site boom feature/function familiarization by a BIK tech
Options at Extra Cost:
Additional grapple saw – Mecanil SG 160 Grapple saw with spare parts kit and holder on deck
Front Wheel Drive conversion
– to be able to have 6-wheel drive for off-road use
Draw plate at rear of truck frame with Heavy Duty air pintle hook and Reese receiver w/brake actuator (dual hitches)
Aluminum single man self-levelling basket
Mat rack behind the cab or mounted on top of deck at rear
a
TC-104 – 104’ Vert Reach Version
– with Mecanil SG-220 (instead of SG-280)
