New Power ND22
Price excl. VAT
POA
10
Favorite
Share
Save searchPrint
INFO
Product category / Group
Crawler dozers
Brand / model
New Power ND22
Mnftr year
2020
Condition
New/unused
Location
Jining,shandong, china
Country
China
Mascus ID
9144943D
DETAILS
Blade type
Straight blade
Undercarriage
Tracked
Emission level
Stage II / Tier II
Engine
Cummins NT855-C280S10
engine output
175 kW (238 hp)
Track width
560 mm
Transport dimensions (LxWxH)
5492000 x 3726000 x 3742000 mm
Production country
China
Delivery terms
FCA, DAT, DAP, FOB, CFR
Accessories
Air conditioning
Multi shank ripper
Single shank ripper
Engine heater
Other information/spec
Model ND22
Engine model Cummins NT855-C280S10
Rated power(kw/rpm) 175/1800
Displacement(L) 14.01
Max.torque(N.m/rpm) 1030/1250
Operating weight(Kg) 23500
Dimension(no ripper)(mm) 5492×3726×3742
Min ground clearance(mm) 405
Ground pressure(MPa) 0.072-0.077
Track shoe width(mm) 560/610/660
Track gauge(mm) 2000
Dozing capacity( m³) 6.4
Blade width(mm) 3725
Blade height(mm) 1315
Max drop below ground(mm) 540
Pitch(mm) 216
Quantity of track link 38
Quantity of Carrier rollers 4
Quantity of Track rollers 12
Max pressure(MPa) 14
Discharge(L/min) 262
Max tractor force(KN) 202
Grade ability(°) 30
Forward(km/h) 3.6/6.5/11.2
Reverse(km/h) 4.3/7.7/13.2
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 China
